Key
Battery checker with built in cell balancing
Advanced Servo testing feature helps with model setup
Spektrum Smart battery technology allows users to take advantage of Smart Battery
Easy to read full color display
Qualcomm 3.0 compatible USB power port with Quick Charge for compatible Android and IOS devices (up to 12v and 2 amps)
Update port for easy access to updates and new
Working voltage: 5.0V-36V
Input voltage 1s : 0.8V-15V
Input voltage 2-8S : 0.8V-4.8V
Battery cells : 1-8S
Voltage measurement accuracy : 0.005V @ 4.2V
Balancing cells accuracy : < 0.005V
Support USB charging : QC 2.0 / 3.0, BC1.2, Maximum output 12V/2A
Support smart battery : Charging and discharging setting, read battery info and USAge history.
Supported Batt. Type : LiHv (1-8S) / LiPo (1-8S) / LiFe(1-8S) / Lilon (1-8S) / NiMh /Cd(1-10S)
Display : 2.4320240 260, 000 color IPS LCD
Dimension : 80 X 55 X 19 mm
Weight : 59g
Operating Temperature: 0-40
Working Humidity: 10%-90%RH (noncondensing)
Storage Temperature: -20-60
Storage Humidity: 5%-90%RH (noncondensing)
Servo PWM Output Hz: 1520uS = 50Hz / 760uS = 333Hz
